TIANDY POE SWITCH TC-P3S06 6CH

Deskripsi

6 Port PoE: Dilengkapi dengan 4 port PoE untuk mendukung perangkat seperti kamera IP dan akses point.
Konektivitas Fleksibel: 2 port RJ45 uplink memungkinkan koneksi dengan perangkat tambahan dengan kecepatan 10/100Mbps.
Garansi Pabrik Produksi: Produk dilengkapi dengan garansi dari pabrik untuk memberikan ketenangan pikiran pada setiap pembelian.
Kombinasikan keandalan dan performa tinggi dalam satu perangkat yang sederhana dan efektif!

TIANDY TC-P3S06 Spec:F/0420/AT/55 6 Port PoE Switch

KEY FEATURES

4*10/100Mbps PoE Ports + 2*10/100Mbps RJ45 Uplink Ports
Comply with IEEE 802.3、IEEE 802.3u、IEEE802.3xs standard
Ethernet port supports 10/100Mbps adaptive
Support POE Priority(QOS)：1>2>3>4(The port in front has higher priority)
Flow control mode: full-duplex adopts IEEE 802.3x standard, half-duplex adopts back pressure standard
Support Port Auto-flip（Auto MDI/MDIX）
Adopting store-and-forward switching mechanism
Panel indicator monitoring status and help failure analysis
With three gears and one key intelligent dip switch, support VLAN, Default, Extend three modes
Support port lightning surge: common mode 4KV (level C); Electrostatic ESD: air 8KV, contact 6KV (level C)

Specifications :
– Power Tiandy TC-P3S06 Spec: F/0420/AT/55
– Power AC INPUT (100-240V)
– Ethernet 4*10 / 100Mbps PoE Ports, 2*10 / 100Mbps RJ45 Uplink Ports
– Bandwidth 1.2 Gbps
– Throughput 0.8928Mpps
– Packet Buffer 448K
– MAC Address 1K
– Transfer Mode : Store and forward
– Network Protocol : EEE802.3 (10Base-T), IEEE802.3u (100Base-TX), IEEE802.3x (Flow control)
– PoE Protocol IEEE802.3af (15.4W), IEEE802.3at (30W),
– POE port output voltage: DC 52V,
– POE power supply core: 1 / 2+; 3 / 6-
– Industrial Standard : EMS: EN61000-4-2 (ESD),
EN61000-4-5 (Surge)
– Network Medium : 10Base-T: Cat3, 4, 5 or above UTP / STP (≤100m),
100Base-TX: Cat5 or above UTP / STP (≤100m)

**Function
– LED Indicators PWR (Power Supply), Mode (DIP),
1-6 Green (Link & Data), POE Max (Power)
– PWR On: Powered on,
Off: Powered off
– POE LED Buttons Dual color light selection: default green (link data),
switch yellow light (POE)

**DIP Switch
– VLAN: (Port Isolation Mode). In this mode, the PoE ports (1-4) of the switch cannot communicate with each other and can only communicate with the Uplink port (5, 6). The port AI mode (PoE Watchdog) is turned on.
– Default Default: (Normal Mode). All Ports can communicate with each other, the transmission rate is 10 / 100Mbps adaptive; The port AI mode is disabled
– Extend Extend: (Link Extension Mode). 1-4 ports force 10M, link 220M. The port AI mode (PoE Watchdog) is turned on.
